Smart Gates System

Smart Gates System

ELID Matrix V integrates with Smart Gates for a secure and powerful automation of entrance control. Pedestrian, turnstile and passenger physical access control equipment can be accessed within the full integrated system.

Software

Matrix V

  • 18 Modules ….and still expanding
  • Door Access Management
  • Intrusion Alarm Monitoring
  • Lift Access Control
  • Vehicle Access Control
  • Lobby/ Visitor Management
  • CCTV

WinPro 2

  • Allows concurrent multi-user system access
  • Intuitive interface for systems configuration and administration
  • Provides real-time activity monitoring
  • Integrates seamlessly with ELID Time Attendance Software
  • Comprehensive transaction and audit trail reports
  • Area trace – security checking
  • Alarm monitoring feature
  • Supports SMS and email alert notification
  • Behavioral analysis feature

E.Win

  • Central access and alarm monitoring and setting
  • Real-time activity monitoring
  • Generate transaction reports
  • User access right and audit trail report – system security
  • Area trace – security checking
  • Built-in time attendance software
  • Access and view the system anywhere (Web View Module)
  • Email alert (Email Module)
  • Support dial-up and leased line modems (Modem Module)

Controller

EL5030

  • Configurable to work on 3 or 5 or 8 access portals
  • Large database of 15,000 card users and 25,000 offline transactions
  • Card database upgradable to an astonishing 300,000 card users
  • Reader support: Magnetic, Bar Code, EM/HID Proximity, Mifare, Biometric Devices
  • 32-bit-low-power and high performance microprocessor
  • Peer-to-peer communication with other EL 5000 series controller for data sharing intelligence
  • Multi-function; Standard Access Mode/Car-Park control/Time clocking –Late reasoning mode
  • Enhanced Anti-passback capabilities ( Hard/Soft/Alarm)
  • Support an expansion slot for future-proof requirements
  • 40 holidays set; 99 timezones with 99 timers with 4 time intervals
  • Built in tamper alarm, battery low, AC fail

EL2205

  • Separate control unit – high security
  • Backlit 2×20-character LCD display and 16-key keypad
  • Reader support: Magnetic, Bar Code, EM/HID Proximity, Mifare, Biometric devices
  • Database
    • Standard EL2205 (1,600 cards & 2,000 transactions OR
      3,200 cards & 1,000 transactions)
    • EL2205 with extended memory (6,400 cards & 4,000 transactions OR
      12,800 cards & 2,000 transactions)
  • 24 timers and 10 time zones
  • Provide Dual Card and Special Card feature
  • Card, Card + PIN, PIN
  • Supports Anti-Passback
  • Communication Interface: Multi-drop

ER505

  • RS 485 connectivity
  • Support up to 7 different card format
  • Customer Code support for higher security
  • 10 Off Line supervisory card

Reader

ERM823

  • Reading range: up to 8 cm
  • Power consumption: 5V / 80 mA
  • Output format: Wiegand 26-bit/ Free Wiegand
  • Dimensions: 85(H)x45(W)x15(D) mm
  • Environmental Rating: IP67, sealed in resin

ERM23

  • Reading range: 3 – 5cm
  • Power consumption: 5V / 50 mA
  • Transmission frequency: 125 kHz
  • Output format: Wiegand 26-bit/ Free Wiegand
  • Dimensions: 120(H)x44(W)x20(D) mm
  • Environmental Rating: IP67, sealed in resin

EK72X

  • Microprocessor: 8-bit 40MHz MCU
  • Communication Interface: RS485 or Wiegand
  • Reading Range: 3cm to 8cm
  • Transmit Frequency:125Khz (EM), 13.56MHz (Mifare)
  • Mode of Operation: Card
  • Output Format: Wiegand 26/40-bit
  • Indicator: LED and buzzer
  • Current Consumption: 80mA
  • Operating Temperature: 0° C to 60° C
  • Colour: Black
  • Operating Voltage: 5 VDC/12 VDC
  • Protection: Surge protection, Water proof
  • Dimensions: 85(H)x45(W)x15(D) mm

ERH923

  • Reading range: up to 5 cm
  • Power consumption: 5V / 50 mA
  • Output format: Wiegand
  • Dimensions: 110(H)x44(W)x35(D) mm
  • Environmental Rating: IP67, sealed in resin

ERH23L

  • Reading range: up to 5 cm
  • Power consumption: 5V / 50 mA
  • Output format: Wiegand
  • Dimensions: 120(H)x44(W)x20(D) mm
  • Environmental Rating: IP67, sealed in resin

ER929

Convenient
The ER929’s unique features are perfectly suited for car park barrier access applications thanks to the extended reading range of up to 5 meters for both smartphones or long range Active Tags. In addition, ER929’s reading capabilities are not affected by vehicle tinting films. This ultimately benefits the user, who will save time by eliminating the need to wind down their windows, particularly during wet weather.
Powerful
The ER929 is both powerful and flexible featuring 3 reading technologies and support for 4 types of reading devices: Smartphone, long range Active Tag, MIFARE smart card and EM proximity card.
Compatible
The ER929 integrates seamlessly with all ELID hardware and also 3rd party controllers with standard WIEGAND outputs.

ER928

  • Reading range: up to 5 cm
  • Power consumption: 12V / 150 mA
  • Output format: Wiegand 26-bit/ Free Wiegand
  • Dimensions: 110(H)x44(W)x35(D) mm
  • Environmental Rating: IP67, sealed in resin

ER828

  • Reading range: up to 5 cm
  • Power consumption: 12V / 150 mA
  • Output format: Wiegand 26-bit/ Free Wiegand
  • Dimensions: 85(H)x45(W)x15(D) mm
  • Environmental Rating: IP67, sealed in resin

ERM923

  • Reading range: up to 5 cm
  • Power consumption: 5V / 50 mA
  • Output format: Wiegand 26-bit/ Free Wiegand
  • Dimensions: 110(H)x44(W)x35(D) mm
  • Environmental Rating: IP67, sealed in resin

Smart Gates

Full-Height Turnstile Gate (CQL-1500-FH)

The full height turnstile is an upgraded version of the tripod turnstile with a 120-degree tripod arm and a 90-degree cross arm for different application scenarios, full height turnstile heights up to 2.3 meters, and guardrails on both sides of the revolving door. Can effectively prevent trailing, retrograde, spanning, and other illegal intrusions. It is a high-security level security gate, suitable for places with high-security requirements such as banks and prisons.

CQL1500FH is a single channel full height turnstile, with full cover on top, support outdoor working. 90-degree cross arm or 120-degree tripod arm is optional.

Flap Barrier Gate (CQL-950-FB)

The CQL950FB, which uses the wood-grain transfer paint technology, is perfectly integrated with the entrance of the museum, the designer uses the golden ratio size to make the entrance look more comfortable, and you can feel the artistic atmosphere from the entrance. The flap barrier gate support integrated various reading equipment, such as RFID reader, QR code scanner, face recognition reader. Providing API for secondary development integrated into customer’s ticketing system.

Speed Gate Turnstile (CQL620SB)

The speed gate turnstile is with a high-quality DC brushless servo motor is configured and the advanced servo control system is carried to truly achieve precise control, stable performance with no maintenance.

The lossless mechanism structure is based on German technology adopted to ensure a long lifespan. The matrix-type photoelectric stereoscopic detection technology is adopted to sensitively detect the behaviors that threaten the passageway safety, such as illegal intrusion, reverse passing, tail-gating, and give out alarms through sound, light, etc. The turnstile can be combined with other security systems.

CQL620SB optical turnstile speed gate slim body and transparent swing barrier can make pedestrian traffic more pleasant and better traffic experience.

FirstLane

The FirstLane swing door speedgate offers unbeatable value for money whilst ensuring safety and quality have not been compromised. Thanks to its black painted steel housing, combined with the elegance of glass, FirstLane speed gate meets stylish and architectural trends. FirstLane provides a high bi-directional flow and safety without compromise. Its exclusive DIRAS detection system ensures precise user tracking for maximum safety and security. Even more intuitive and easy to use thanks to the new dynamic LED lighting, FirstLane combines high throughput with state-of-the-art detection.

Main Benefits

    • Automation of pedestrian access control
    • Restricts access to secured zones
    • Low cost of ownership
    • Employee and visitor Entry/Exit tracking
    • Reduced need for manned entrance
    • Easy to install
    • Low energy consumption for a low carbon footprint

Applications

  • Office buildings, head offices and administrative sites
  • Schools, universities and colleges
  • Gyms and fitness centres
  • Government buildings and institutions

SlimLite 960 Barrier Optical Turnstiles

AESTHETICS
• Minimal footprint
• Black powder coated cabinet
• 3/8’’ (10 mm) Glass mobile obstacles
• Custom colors available

SAFETY
• UL2593 listed to ensure maximum user safety
• Electronic user protection
• In the event of power outage, the mobile obstacles will open toward the exit direction and remain open until power is restored
• EGRESS operating mode meets the highest fire safety standards

THROUGHPUT
• Fast opening / closing of swinging mobile obstacles (≤ 1 second)
• Precise pictograms for intuitive use
• Bidirectional passage

RELIABILITY
• Low cost of ownership, minimal maintenance required
• 2 year warranty

SECURITY
• Proprietary DIRAS detection systems providing a high density matrix of infrared beams
• Electromagnetic brake to withstand forced entry attempts
• IP Communications allowing real-time monitoring

SlimLane 950 / 950 SC

The SlimLane 950 double swing door security entrance lane offers a high bidirectional throughput and uncompromising security. With its transparent, elegant design and minimal footprint, the SlimLane 950 is designed to integrate perfectly into any architectural style.

Its wide lane ensures easy access for people with reduced mobility, wheelchairs, large carts or wide objects. Equipped with high processing capacity and an exclusive detection system, the SlimLane 950 guarantees accurate user tracking and prevents any unauthorised use. The SlimLane 950 is a modular product that can be installed as a single or a multi-lane array and can also be combined with the SlimLane 940 standard lane model.

Applications :

  • Banks and insurance companies
  • Government buildings and institutions
  • Office buildings, head offices and administrative sites
  • Schools, universities and colleges
  • Airports

SlimLane 944 / 944 SC

The SlimLane 944 single swing door security entrance lane offers a high bidirectional throughput and uncompromising security. With its transparent, elegant design and minimal footprint, the SlimLane 944 is designed to integrate perfectly into any architectural style. The SlimLane 944 offers a single compact passageway, suitable for confined installation spaces. Equipped with high processing capacity and an exclusive detection system, the SlimLane 944 guarantees accurate user tracking and prevents any unauthorized use.

The SlimLane 944 is a modular product that can be installed as a single or a multi-lane array by combining with the SlimLane 945 Twin dual compact lane, the SlimLane 940standard lane, and SlimLane 950 wide lane models.

Applications :

  • Banks and insurance companies
  • Government buildings and institutions
  • Office buildings, head offices and administrative sites
  • Schools, universities and colleges
  • Airports

SlimLane 945 Twin / 945 SC Twin

The SlimLane 945 SC Twin single swing door security entrance lane offers a high bidirectional throughput and uncompromising security. With its transparent, elegant design and minimal footprint, the SlimLane 945 SC Twin is designed to integrate perfectly into any architectural style.

The SlimLane 945 SC Twin offers a dual compact passageway, suitable for confined installation spaces. Equipped with high processing capacity and an exclusive detection system, the SlimLane 945 SC Twin guarantees accurate user tracking and prevents any unauthorised use. The SlimLane 945 SC Twin is a modular product that can be installed as a single or a multi-lane array and can also be combined with the SlimLane 944 SC single compact lane, the
SlimLane 940 SC standard lane and SlimLane 950 SC wide lane models.

With its innovative and stylish design, the speed gateSlimLane 945 Twin swing door combine high throughput with best in class reliability, while providing a compact footprint in a dual passageway.

SlimLane 940 / 940 SC

The SlimLane 940 double swing door security entrance lane offers a high bidirectional throughput and uncompromising security.

With its transparent, elegant design and minimal footprint, the SlimLane 940 is designed to integrate perfectly into any architectural style. Equipped with high processing capacity and an exclusive detection system, the SlimLane 940 guarantees accurate user tracking and prevents any unauthorized use. The SlimLane 940 is a modular product that can be installed as a single or a multi-lane array and can also be combined with the SlimLane 950 wide lane model.

Applications :

  • Banks and insurance companies
  • Government buildings and institutions
  • Office buildings, head offices, and administrative sites
  • Schools, universities, and colleges
  • Airports

Tripod Turnstile (CQLST10)

Product Code: CQL-ST-10

  • Alloy steel tripod hub prevents mechanical wear
  • Casework and tripod arms manufactured in SUS304 stainless steel
  • Electromagnets for the lock are used only when being activated
  • The compact mechanism ensures the long life of the lubricating oil inside
  • High-quality electrical components
  • The pictogram on the device indicates access permission and direction of movement
  • Specially designed case shape, user-friendly for passers to punch card or finger
  • Flexible reader installation plate.
  • Customers can easily integrate with third-party reader
  • Standard electrical interface for third-party device
  • By using the compact mechanism, the turnstile has more space inside for integration

Waist-height Turnstile (CQL-WT-100)

Product Code: CQL-WT-100

  • Remote control
  • Anti-panic design
  • Counting function
  • Anti-trailing design
  • Internal mechanical
  • Heating system for increase

Swing Barrier (CQL-SB-800H)

Product Code: CQL-SB-800H

  • Elegant style, stainless steel cabinet, advanced system of detection and tracking sensors
  • Finished in brushed AISI 304 stainless steel and acrylic arms
  • Hieroglyphic symbols to inform authorization permission and access situation
  • Detection logic and alarming
  • Failsafe security barrier
  • User safety
  • Customized finish; alternative colors and materials for arms top cover

Swing Gate Turnstile (CQL-SB-600H)

Product Code: CQL-SB-600H

  • Widely used in Commercial Buildings, Airports, Metro Stations, Libraries, Factories, Exhibition Centers, Gyms, and Government Institutions
  • Anti-Tail Gaiting feature built in to prevent unauthorized entry
  • Fast opening and closing time
  • Built-in mechanical lock to prevent forced opening of swing flaps
  • Fail-safe design ensures that the swing flaps retract back into the housing to allow unblocked access in the event of a power failure
  • Active infra-red beams are located in the housing passage to detect personnel or objects crossing the flap barrier to prevent the flaps from causing injury or damage
  • Long service life with low operational cost

Flap Barrier (CQL-FB-400)

Product Code: CQL-FB-400

  • Elegant style, stainless steel cabinet, advanced system of detection and tracking sensors
  • Finished in brushed AISI 304 stainless steel and acrylic arms
  • Hieroglyphic symbols to inform authorization permission and access situation
  • Detection logic and alarming
  • Failsafe security barrier
  • User safety
  • Customized finish; alternative colors and materials for arms top cover
